Multimedia Interface for VW - RNS810 including video release.
c.LOGiC lite VW MFD3 / RNS810, Skoda Columbus, with RVC with STG
c.LOGiC lite Interface AV input with control + camera input + switching signals
The interface allows you to connect any AV source (eg Nachruestgeraete DVD Player, DVB-T tuner) to the OEM navigation system of the vehicle manufacturer. For the AV input is an IR control channel for disposal by the can be controlled by means of buttons on the OEM navigation system the main functions of connected Nachruestgeraete.
The control level can be assigned a fixed preprogrammed IR control code numerous Nachruestgeraete. A detailed list is shown in the infrared code table.
When inserting the Rueckwaertsganges is automatically switched to the Rear Camera Video Input of c.LOGiC lite.
Switching Outputs for Rear Camera and Nachruestgeraete make installation easier, faster and more comfortable.
Connections:
1 x AV input with IR-control channel
1 x video input for Rear Camera (this numbering is not necessary)
Switching signals:
Rear Camera Power (max 0.5A)
Inrush for Nachruestgeraete (max 0.5A)
Compatible with VW, Skoda, Seat
Navigation system MFD2 / RNS2 / MFD3 / RNS510 / RNS810 / Nexus / Columbus / Trinax (16: 9) WITH factory Rear Camera version WITH camera Steuergeraet
